Specifications
- Type4-stroke, overhead valve, single-cylinder, horizontal shaft
- Bore & Stroke77 X 58 mm
- Displacement270 cm3
- Compression Ratio8.2 : 1
- Net Power6.0kW (8.0HP) at 3,600 rpm
- Continuous Rated Power5.1kW (6.8HP) at 3,600 rpm
- Maximum Net Torque17.7 Nm at 2,500 rpm
- Ignition SystemTransistorised magneto ignition
- Starting SystemRecoil (Electric Starter Optional)
- Cooling SystemForced-Air
- CylinderCast Iron Sleeve
- Fuel Consumption at Rated Power2.5 L/h at 3,600 rpm
- Recommended FuelUnleaded
- Lubrication SystemSplash
- Recommended Oil10W/30 API SG
- Fuel Capacity5.3 L
- Oil Capacity1.1 L
- PTO Shaft RotationCounter-clockwise (from P.T.O. side)
