Specifications
- Engine TypeAir-cooled 4-stroke OHV
- Bore x Stroke2.59″ x 2.32″ (66 mm x 59 mm)
- Displacement12.3 cu in (201 cm3)
- Net Power Output5.6 HP (4.2kW) @ 3600 rpm
- Net Torque9.4 lb-ft (12.7 Nm) @ 2500 rpm
- PTO Shaft RotationCounterclockwise (from PTO shaft side)
- Compression Ratio 8.0:1
- CarburetorHorizontal type butterfly valve
- Ignition SystemTransistorized magneto
- Starting SystemRecoil
- Air CleanerDry (paper filter)
- Governor SystemCentrifugal Mechanical
- Fuel Tank Capacity0.24 U.S. gal (.99 liter)
- FuelUnleaded 86 octane or higher
- Oil Capacity0.42 US qt (0.41l)
- Lubrication SystemSplash
