Specifications
- Type4-stroke, overhead valve, single-cylinder, Vertical shaft
- Bore & Stroke68 x 45mm
- Displacement163 cm3
- Compression Ratio8.0 : 1
- Net Power3.2 Kw (4.3HP) at 3600 rpm
- Continuous Rated Power2.0 kW (2.7HP) at 3000 rpm
- Maximum Net Torque9.6 Nm at 2,500 rpm
- Ignition SystemTransistorised magneto ignition
- Starting SystemRecoil
- Cooling SystemForced-Air
- PTO Shaft RotationCounter-clockwise (from P.T.O. side)
- Fuel Consumption at Rated Power1.1 L/h at 3,000 rpm
- Recommended FuelUnleaded
- Lubrication SystemForced splash
- Recommended Oil10W/30 API SG
- Fuel Capacity1.8 L
- Oil Capacity0.65 L
